Category 6 – Modular Patch Cords

Installation zone RECOMMENDATION
1
1
1
1

OCC's Category 6 patch and workstation cords are the perfect compliment to any OCC Category 6 copper system.  In addition, our Category 6 patch cords utilize straight-through pair orientation and are 100% component performance tested. OCC's test methods have formed the basis for standard patch cord component testing methods in TIA/EIA 568-C.2 Category 6 standards.

Applications

  • 1000BASE-T Gigabit Ethernet
  • 100BASE-TX Fast Ethernet
  • 10BASE-T Ethernet
  • Broadband Video
  • 155/622 Mbps ATM
  • Analog Voice/VOiP
  • PoE+
  • All applications developed for operation over Category 6 or class E cabling

Features

  • 100% component performance tested
  • Exceeds TIA 568-C.2 Cat 6 specifications
  • Customizable lengths and colors available
  • Shielded version available
  • Compliant with Power over Ethernet (PoE+) requirements
  • Insulation resistance- 500MΩ minimum
  • Dielectric withstand- 1000 VAC RMS, AC 60Hz or 1414 VDC
  • DC current rating- 1.5 A per conductor at 20°C ambient de-rated to 0.75 A at 60°C
  • Centered modular plugs
  • Slimline strain-relief boot
  • Snag-less

Specifications

Download Drawing(s)
Part NumberDescriptionPDFDWG/ZIP
IPCSIXxxxByyCategory 6 Patch Cord with Boot, PVC, UTP, Class E n/a n/a
IPCSIXxxxByyLZHCategory 6 Patch Cord with Boot, Shielded, LSZH, Class E n/a n/a
PCSIXSxxByyCategory 6 Shielded Patch Cord with Boot Download Download
PCSIXxxByyCategory 6 UTP Patch Cord with Boot Download Download
PCSIXxxyyCategory 6 UTP Patch Cord Without Boot Download Download
ISPCSIXxxxByyCategory 6 Patch Cord with Boot, Shielded, PVC, Class E n/a n/a
ISPCSIXxxxByyLZHCategory 6 Patch Cord with Boot, Shielded, LSZH, Class E n/a n/a
*Replace "xx" with length in feet; replace "yy" with color code: 06 = gray, 01 = yellow ** Ex: = PCSIX08B06 - Category 6 patch cord, 3 feet, with boot, gray Additional colors available. Contact OCC for ordering information.
